Built-in Fan Version
Weatherproof Digital Signage 32 Inch Horizontal Fan Cooling for Retail Windows
High-performance 32-inch outdoor digital signage commercial screen by ZXTLCD. Features IP65 weatherproofing, 2500+ nits sunlight readability, & factory ...
Specifications
- Model
- ZXTLCD-OUTFHE320G
32 Inch Horizontal Outdoor Digital Signage for Retail Window Promotions
This 32 Inch Horizontal Outdoor Digital Signage is intended for small exterior positions where a full-height advertising kiosk would be disproportionate. Its wide screen can sit within a storefront fixture, exterior service counter or compact promotional enclosure.
The image shows a white and light-blue surround carrying colourful retail content. Its appearance is lighter and less industrial than many large outdoor cabinets.
32 Inch Outdoor landscape embedded digital signage Built-in Fan for Ventilation | ||
|---|---|---|
The containment structure | The material and feature of shell | IP65 waterproof enclosure, 1.5mm zinc coated steel, waterproof and anti-dust design. |
Glass feature | with 6mm Tempered explosion-proof Glass above the screen panel | |
Panel Spec | Backlight type | DLED |
Display size(mm) | 697*392 | |
Display ratio | 16:9 | |
Resolution | 1920*1080 | |
Brightness | 2000-2500cd/㎡ | |
Contrast Ratio | 3500:1 | |
View angle | 178°（H）/178°（V） | |
Response time | 6ms | |
Lifespan | 50000H | |
Touch Overlay for Interactivity(Optional) | Touch style | Projected Capacitive Touch screen |
Touch points | 10 points | |
Ambient light sensor | auto dimming, with light sensor, automatically adjust the brightness. | |
Built-in Android Media Player PCB Board Configuration | Processor Chip | RK3576, six core |
RAM | 4GB | |
Flash Memory Card | 32GB | |
Wifi and 4G | Yes | |
Version | Android 14.0 | |
Built-in PC Board Configuration(Optional) | CPU | Intel Core i5 Processor |
RAM | 8GB DDR4 | |
Storage | 128GB SSD | |
Operating System | Windows 10 / Windows 11 | |
Graphics | Integrated Intel UHD Graphics | |
Network | LAN + WiFi Wireless Network | |
Media Format | Video format | wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 etc. |
Audio format | MP3, WMA | |
Photo format | BMP, JPEG, PNG, GIF etx | |
Onboard interface | Network port | RJ45, 10M/100M Adaptive Ethernet |
HDMI | 1 | |
USB | 2 | |
Camera | Built-in 5 Megapixel Camera with 1920X1080 Resolution | |
Speakers | Dual side speakers for Audio | |
ECU | Switch power supply | Industrial Power supply |
Waterproof speaker | High quality waterproof 10W speaker | |
Thunder Preventer | The tree-level lightning protection | |
Leakage protective device | Defend Electricity Leakage | |
Timer | Set up on/off time on day/week/month | |
Outdoor OMC system（optional） | inlcudes 10 kinds sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). | |
Problem and staus monitoring software included. | ||
Touble shooting by software included. | ||
Use softwae Remote Check key working performance by Group | ||
Unnormal work alarm generation | ||
Built-in Fan for Ventilation | Intelligent Straight ventilation Cooling system | Intelligent cooling system, unique design of air duct and main board, automatic adjust wind speed |
Intelligent temperature sensing system, Once high temperature arises, the display shutdown automatically | ||
Environment | Working temperature | 0℃～+50℃(Optional heater installed up to -20℃～+50℃) |
Working humidity | 10%～90% | |
Working Voltage | AC110-240V,50/60Hz | |
Max Power Consumption | ≤230W | |
Mechanical Para | Machine seize H*W*D(mm) | 560*860*150 |
Net weight(Kg) | 40 | |
Package size H*W*D(mm) | 760*1160*300 | |
Gross weight(Kg) | 60 | |
Best Used for One Product or One Instruction
The limited screen area encourages focused communication. A retailer can show one featured product, a current price or a short pickup instruction without covering a large part of the storefront.
Suitable content includes:
- One-item promotions
- Daily restaurant offers
- Outdoor service-counter instructions
- Store opening times
- QR-linked product information
- Short brand animations
The 32 Inch Horizontal Outdoor Digital Signage should not be filled with miniature versions of several posters. A customer walking past will not have time to study them.
Think in Landscape Format
A wide screen works well for a product image beside a short text block. It can also show opening hours and directional arrows on the same page.
Content should be prepared at the screen’s native aspect ratio. Stretching portrait artwork creates empty space or distorted images and weakens the professional appearance.
Outdoor Installation and Upkeep
The enclosure is designed for weather-exposed use and uses built-in fan cooling. Ventilation openings must remain clear when the screen is installed inside another fixture.
The front surface will require regular cleaning, especially at pavement level where dust and water marks accumulate quickly. The 32 Inch Horizontal Outdoor Digital Signage can remain visually effective when both the campaign and the physical screen are kept current.
